Mineral insulated cable (fireproof cable)

All Product Categories

Mineral insulated cable (fireproof cable)

Highly compacted insulating material that prevents steam, gas and flame from passing between equipment parts connected to the cable and is suitable for use in locations where there is a risk of explosion.

Voltage	Type	Model
0.6/1KV	Rigidity	BTTZ BTTQ BTTVZ BTTYZ WD-BTTYQ
0.6/1KV	Flexibility	BTTRZ BTLY YTTW DW-YTTWY TRVV PUR-TRVV

Parameters	Rigid mineral insulated cable	Flexible mineral insulated cable
Rated voltage	0.6/1kV	0.6/1kV
Operating temperature	-40°C to +90°C (long-term operation)	-40°C to +90°C (long-term operation)
Maximum short-term temperature	250°C (maximum short-term temperature)	250°C (short-term temperature tolerance)
Minimum bending radius	15×cable outer diameter	10×cable outer diameter
Conductor material	Copper or tinned copper (usually copper conductor)	Copper or tinned copper (usually copper conductor)
Conductor structure	Single, stranded (according to specifications)	Twisted or single strand (depending on specification)
Insulation material	Mineral insulation (magnesium oxide, mineral powder)	Mineral insulation (magnesium oxide, mineral powder)
Sheath material	Copper/aluminum tape, PVC, PE, etc.	Copper/aluminum tape, PVC, PE, etc.
Cable structure	Conductor → mineral insulation → outer sheath (metal sheath)	Conductor → Mineral insulation → Outer sheath (metal sheath optional)
Cable cross-sectional range	1.5mm² ~ 400mm²	1.5mm² ~ 400mm²
Cable outer diameter	Depending on the cross section, about 4.5mm ~ 50mm	Depending on the cross section, about 4.5mm ~ 50mm
Cable weight	6 ~ 20 kg/m (according to the cross section and sheath)	6 ~ 20 kg/m (according to the cross section and sheath)
Flame retardancy	Comply with IEC 60332-1/2 and other standards	Comply with IEC 60332-1/2 and other standards
Fire resistance	Mineral insulation layer can work continuously at high temperatures	Mineral insulation layer can work continuously at high temperatures
Anti-electromagnetic interference	Shielding layer (copper or aluminum tape) can effectively suppress electromagnetic interference	Shielding layer (copper or aluminum tape) can effectively suppress electromagnetic interference
Corrosion resistance	Excellent acid and alkali resistance and corrosion resistance	Excellent acid and alkali resistance and corrosion resistance
Tensile strength	High (suitable for fixed wiring)	Medium (suitable for frequent bending, drag chains, etc.)
Oil resistance	Good	Good
Aging resistance	Excellent	Excellent
