Mining power cable

All Product Categories

Mining power cable

Adaptable to severe cold or high temperature environments, especially suitable for use in places with large temperature differences such as mines, ensuring the reliability of power supply

Model	Description
MVV	PVC insulated PVC sheathed power cable can be used for fixed laying of power lines in coal mines to provide power for various electrical equipment.
MYJV	XLPE insulated PVC sheathed power cable, XLPE insulation has better heat resistance and electrical properties, suitable for places with high cable performance requirements.
MYJV22	XLPE insulated steel belt armored PVC sheathed power cable, has the advantages of XLPE insulation and the mechanical protection performance of steel belt armor, suitable for occasions that need to meet both power transmission and mechanical protection requirements.

Parameters	Power cable for mining
Rated voltage	0.6/1kV 3.6/6kV 8.7/15kV
Conductor material	Copper or aluminum alloy
Conductor structure	Single conductor or multiple stranded conductors
Insulation material	PVC, XLPE, rubber, etc.
Insulation thickness	Depending on the voltage level and specifications, usually 1.0 mm ~ 3.0 mm
Shielding type	Copper tape shield, aluminum foil shield, metal shield
Outer sheath material	PVC, PE, rubber, etc.
Outer sheath thickness	Usually 1.5 mm ~ 5.0 mm
Operating temperature	-20°C ~ +70°C (common) or higher
Minimum operating temperature	-40°C (adaptable to severe cold environments)
Short circuit resistance temperature	160°C ~ 250°C
Fire resistance	Fireproof, fire-resistant or flame-retardant
Abrasion resistance	With good wear resistance and tensile strength
Current carrying capacity	Depending on the cable cross-sectional size and rated voltage
Cable structure	Single-core, three-core or multi-core cable
Service life	≥ 30 years
Cable weight (approx.)	7~20 kg/m (depending on specifications)
